Sink units & basins
Sink tables
- Entirely made of matt ground CNS – 1.4301, grain 320
- Standard sink table cover – with all-round slosh guard, dropped edges on three sides as standard, upstand on wall side 50 mm, sound-absorbing underlay, reinforced with profiles
- Cover at customer request with material thickness of 1.0, 1.5 or 2.0 mm, with beaded edging, moulded draining boards, sink, upstand and dropped edging freely selectable
- Seamlessly deep-drawn sink, welded without joints and polished
- Basin available in various sizes and depths, factory-fitted with standpipe valve and drain fitting
- Frame construction made of square tubing with three-sided basin panel open (accessible underneath), with storage shelf or removable grid shelf or with hinged or sliding doors
- Ground clearance 150 mm/200 mm at working height 850 mm/900 mm, feet height-adjustable +/- 15 mm
- Options:
- custom working height
- single-hole mixer tap 1/2" chrome-plated
- two-hole mixer tap 3/4" chrome-plated
- swing spout pre rinse spray hose
Hand washing basins
- Material CNS-1.4301 with micro-polished surface
- Hand washing basin with three-sided basin cover
- Seamlessly deep-drawn basin
- Keyhole for wall mounting
- Drain and overflow fitting included
- Option:
- Mixer tap ½" with two handles
- Sensor mixer tap for mains connection or battery operation
Hand washing basin and drainage sink combinations
- Hand washing basin 340x240x150 mm, smoothly welded in
- Top basin panel removable
- Sink basin 370x340x150 mm, welded in recessed, with CNS hinged grating, complete with drain fittings
- Keyhole for wall mounting
- Lower front panel removable in the case of base installation
- Single-hole two-handle mixer tap ½" for both basins – on right
- Standard feet height 150 mm (adaptable to project) or without feet for wall mounting or base installation
- Option:
- Sensor mixer tap for mains connection or battery operation
