Intermediate and installation components
Work tables
- Worktop made of chromium-nickel steel (1.0 mm), sound absorber and reinforced by profiles
- SUA xx0: Box drawer with roller slides, full extension and end stop
- Drawer panels double walled
- SUA xx1: Neutral switch panel instead of drawer with possibility for installation of sockets and/or with mounted column mixer tap for filling pots etc.
- Column mixer tap mounted on the countertop for the filling of pots etc.
- Substructure: Open cabinet or with wing doors
width | 400 mm | 500 mm | 600 mm |
Free-standing appliances with box drawers | SUA 040 | SUA 050 | SUA 060 |
Free-standing appliances with neutral switch panels | SUA 041 | SUA 051 | SUA 061 |
Table-top/Wall appliances | SUA 048 | SUA 058 | SUA 068 |
Intermediate and installations components
- Fastened between two appliances by means of support brackets
- Closed on three sides
- Worktop made of chromium-nickel steel, sound absorber, reinforced by profiles
- Neutral switch panel and possibility for installation of sockets in the front panel and/or with mounted column mixer tap for filling pots etc. on the working surface
width | 200 mm | 300 mm |
Free-standing appliances | SUA 021 | SUA 031 |
Table-top/Wall appliances | SUA 029 | SUA 039 |
